Product features

• Dome nut: stainless steel 1.4305
• Lamellar insert: polyamide PA 6 V-2
• Sealing ring: polychloroprene-Nitrile rubber CR/NBR
• Gland body: stainless steel 1.4305
• O-ring: Nitrile rubber NBR
• Connecting thread: metric, as per EN 60423
• Integrated anchorage, protection against twisting, wide sealing and clamping range, easy-to-install
• Temperature range: -20 °C ... +100 °C (dynamic)
• Temperature range: -40 °C ... +100 °C (static, short term)
• Protection grade: IP68, IP69K (tested for M12-M25, M50 and M63)

Additional information

Test standard: UL 514B. UL/CSA-File: E140310. DNV-GL certificate: TAE0000386.
