Description
Product features
- Base body: Brass CuZn39Pb3, tin-plated
- High-current PCB connection up to 1000 A
- For use where smaller press-in forces are required
- For use in layouts which do not allow pins all across the base
- For attaching cable lugs, midi fuses, mega fuses and more to PCBs
- Holding force: according to IEC 352-5
- Press-fit force: max. 250 N per pin / min. 40 N per pin
- Press-out force: min. 30 N per pin
- PCB thickness: min. 1,6 mm
