Product features

• Housing material: polyamide (PA 6.6) natural color
• Self-extinguishing: UL 94 V-2; IEC 695-2-1 to 850 °C and IEC 695-2-2
• Working temperature: max. 125 °C
• Short-time working temperature: max. 160 °C
• Test voltage: 2500 V
• Test current: 24 A
• Clamps: brass, nickel plated
• Screws: M3x5, steel, zinc plated

Additional information

1 to 11 way terminal blocks available on request Wire protection version: Stainless steel According standards: EN 60998-1: 2004 / EN 60998-2-1: 2004 EN 60335-1: 2002 + A2: 2006 (S.C. 30.2.3) IEC/EN 60695-2-11
